Product no 1000983688
Model VIGI NVR1008H-8MP
Brand TP-LINK Technologies
EAN 6935364072346
Weight 2.37 kg
Produktbeskrivelse | TP-Link VIGI NVR1008H-8MP V1 - standalone NVR - 8 kanaler |
Enhedstype | NVR - 8 kanaler - netværket - rackversion |
Understøttede IP Kameraer | 8 |
Komprimerings Format | H.264, H.265, H.264+, H.265+ |
Billed Opløsning | 1280x720, 1920x1080, 1024x768, 1680x1050, 1280x1024, 1440x900, 3840x2160 |
Understøttede HardDrev | Antal: 1 - total kapacitet: 10 TB |
Spænding | 53.5 V |
Dimensioner (B x D x H) | 29.4 cm x 18 cm x 4.4 cm |
Producentgaranti | 3 år |
General | |
---|---|
Compliant Standards | Plug and Play, IEEE 802.3af, IEEE 802.3at |
Compression Format | H.264, H.265, H.264+, H.265+ |
Device Type | NVR - rack-mountable |
Image Resolution | 1280x720, 1920x1080, 1024x768, 1680x1050, 1280x1024, 1440x900, 3840x2160 |
IP Cameras Supported | 8 |
Package Content | Mouse, HDD screws |
Video Channels | 8 |
Warranty | 3 years |
Security DVR | |
Features | 80Mbps Incoming Bandwidth, 60Mbps Outgoing Bandwidth |
Networked | Yes |
Playback Search | Date/time, event |
Hard Drive | |
Interface | Serial ATA |
Quantity Supported | 1 |
Supported Max Total Capacity | 10 TB |
Video Server | |
Features | Two-way audio support |
Networking | |
Features | ONVIF support, 113W PoE+ power budget |
Network Interfaces | Ethernet 10Base-T/100Base-TX |
Supported Protocols | DHCP, DNS, NTP, TCP/IP, UPnP |
Connections | |
Audio Input Ports | RCA x 1 |
Audio Output Ports | RCA x 1 |
Network Port | 10/100Base-T |
Other Ports | USB 2.0 x 2 |
Video Input Ports | RJ-45 x 8 |
Video Output Ports | HDMI x 1, VGA x 1 |
Power | |
Power Consumption | 4.82 Watt |
Power Consumption Details | Without HDD |
Voltage | 53.5 V |
Dimensions & Weight | |
Depth | 18 cm |
Height | 4.4 cm |
Width | 29.4 cm |
Environmental Parameters | |
Max Operating Temperature | 55 °C |
Min Operating Temperature | -10 °C |
