Product no 988853926
Model TL-SG2210P
Brand
Go to brand's website
EAN 6935364080259
Weight 1.28 kg
Produktbeskrivelse | TP-Link TL-SG2210P 8-Port Gigabit Smart PoE Switch with 2 SFP Slots - switch - 8 porte - Administreret |
Enhedstype | Switch - 8 porte - Administreret |
Undertype | Gigabit Ethernet |
Porte | 8 x 10/100/1000 + 2 x SFP |
Power Over Ethernet (PoE) | PoE |
PoE-budget | 53 W |
Præstation | Båndbredde: 20 Gbps<br>Fremsendelsespræstation: 14.9 Mpps |
Kapacitet | Aktive VLANer: 512 |
MAC adresse table størrelse | 8K indtastningshukommelse |
Jumborammesupport | 9216 byte |
Routingprotokol | IGMPv2, IGMP, IGMPv3 |
Protokol til fjernadministration | SNMP 1, RMON 1, RMON 2, RMON 3, RMON 9, SNMP 3, SNMP 2c, HTTP, SSH, SSH-2, CLI |
Egenskaber | Datatransport, auto-negotiation, VLAN-understøttet, auto-uplink (auto MDI/MDI-X), IGMP snooping, Syslog understøttet, portspejling, håndterbar, Broadcast Storm Control, Multicast Storm Control, Unicast Storm Control, firmware kan opgraderes, SNTP-understøttet, Spanning Tree Protocol (STP) support, Rapid Spanning Tree Protocol (RSTP) support, Virtual Cable Test (VCT) teknologi, Multiple Spanning Tree Protocol (MSTP) support, Quality of Service (QoS), SSH support, blæserløs, Management Information Base (MIB), Class of Service (CoS), Loopback, DiffServ Code Point (DSCP) support |
Overensstemmelsesstandarder | IEEE 802.3u, IEEE 802.3i, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3af, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1s |
Effekt | AC 120/230 V (50/60 Hz) |
Dimensioner (B x D x H) | 20.9 cm x 12.6 cm x 2.6 cm |
Systemkrav | UNIX, Apple MacOS, Novell NetWare, Microsoft Windows 98 Second Edition, Linux, Microsoft Windows NT / 2000 / XP, Microsoft Windows Vista, Microsoft Windows 7 / Windows 8 |
General | |
---|---|
Authentication Method | Secure Shell (SSH), Secure Shell v.2 (SSH2) |
Capacity | Active VLANs: 512 |
Compliant Standards | IEEE 802.3u, IEEE 802.3i, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3af, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1s |
Device Type | Switch - 8 ports - managed |
Enclosure Type | Desktop |
Encryption Algorithm | TLS 1.0, SSL 3.0, SSL 2.0 |
Features | Flow control, auto-negotiation, VLAN support, auto-uplink (auto MDI/MDI-X), IGMP snooping, Syslog support, port mirroring, manageable, Broadcast Storm Control, Multicast Storm Control, Unicast Storm Control, firmware upgradable, SNTP support, Spannin |
Jumbo Frame Support | 9216 bytes |
MAC Address Table Size | 8K entries |
Performance | Bandwidth: 20 Gbps | Forwarding performance: 14.9 Mpps |
PoE Budget | 53 W |
Ports | 8 x 10/100/1000 + 2 x SFP |
Power Over Ethernet (PoE) | PoE |
Remote Management Protocol | SNMP 1, RMON 1, RMON 2, RMON 3, RMON 9, SNMP 3, SNMP 2c, HTTP, SSH, SSH-2, CLI |
Routing Protocol | IGMPv2, IGMP, IGMPv3 |
Status Indicators | Port transmission speed, power, system, PoE, link/activity |
Subtype | Gigabit Ethernet |
Expansion / Connectivity | |
Interfaces | 8 x 1000Base-T RJ-45 PoE | 2 x Gigabit LAN SFP |
Power | |
Power Consumption Operational | 63.4 Watt |
Power Device | External power adapter |
Voltage Required | AC 120/230 V (50/60 Hz) |
Miscellaneous | |
Compliant Standards | FCC, RoHS |
Included Accessories | Rubber feet |
Software / System Requirements | |
OS Required | UNIX, Apple MacOS, Novell NetWare, Microsoft Windows 98 Second Edition, Linux, Microsoft Windows NT / 2000 / XP, Microsoft Windows Vista, Microsoft Windows 7 / Windows 8 |
Software Included | Drivers & Utilities |
Dimensions & Weight | |
Depth | 12.6 cm |
Height | 2.6 cm |
Width | 20.9 cm |
Environmental Parameters | |
Humidity Range Operating | 10 - 90% (non-condensing) |
Humidity Range Storage | 5 - 90% (non-condensing) |
Max Operating Temperature | 40 °C |
Max Storage Temperature | 70 °C |
Min Operating Temperature | 0 °C |
Min Storage Temperature | -40 °C |
