StarTech.com Netværksadapter PCI Express x1 1Gbps
StarTech.com 1 Port PCIe Gigabit Network Server Adapter NIC Card - Dual Profile - Gigabit Desktop Adapter REV E Intel 6 Chip support (ST1000SPEX2) - Netværksadapter - PCIe lavprofil - Gigabit Ethernet - for P/N: ET91000SM10, ET91000SM20
229,00DKK183,20DKK excl. VAT
-
Product no 988493160
Model ST1000SPEX2
Brand StarTech.com
EAN 0065030849265
Weight 0.12 kg
-
Product information and specifications are guiding only. Without notice, these can be subject to change by the manufacturer. This applies for product images as well.
| Produktbeskrivelse | StarTech.com 1 Port PCIe Gigabit Network Server Adapter NIC Card - Dual Profile - Gigabit Desktop Adapter REV E Intel 6 Chip support (ST1000SPEX2) - netværksadapter - PCIe - Gigabit Ethernet |
| Enhedstype | Netværksadapter |
| Model | Indstikskort - lavprofil |
| Grænseflade (bus) type | PCI Express x1 |
| Porte | Gigabit Ethernet |
| Dimensioner (B x D x H) | 2 cm x 12 cm x 8 cm |
| Vægt | 36 g |
| Dataforbindelsesprotokol | 10Mb LAN, 100Mb LAN, 1GbE |
| Dataoverførselshastighed | 1 Gbps |
| Processor | 1 x Realtek Semiconductor RTL8111E |
| Overensstemmelsesstandarder | IEEE 802.3, IEEE 802.3u, IEEE 802.3ab |
| Systemkrav | Microsoft Windows Server 2003, Microsoft Windows Server 2008 R2, Microsoft Windows Server 2012, Microsoft Windows Server 2012 R2, Apple MacOS X 10.6 - 10.9, Microsoft Windows Server 2016, Microsoft Windows 2000/XP/Vista/7/8/8.1/10, Linux 2.4.x to 4.11.x LTS versions only, Microsoft Windows Server 2019 |
| Producentgaranti | 2 års garanti |
| Designet for | P/N: ET91000SM10, ET91000SM20 |
| General | |
|---|---|
| Device Type | Network adapter |
| Form Factor | Plug-in card - low profile |
| Interface (Bus) Type | PCI Express x1 |
| Networking | |
| Compliant Standards | IEEE 802.3, IEEE 802.3u, IEEE 802.3ab |
| Connectivity Technology | Wired |
| Data Link Protocol | Ethernet, Fast Ethernet, Gigabit Ethernet |
| Data Transfer Rate | 1 Gbps |
| Features | Full duplex capability, VLAN support, wake on LAN (WOL), auto-uplink (auto MDI/MDI-X), Jumbo Frames support |
| Ports | Gigabit Ethernet |
| Status Indicators | Link/activity |
| Processor / Memory | |
| Processor | 1 x Realtek Semiconductor RTL8111E |
| Expansion / Connectivity | |
| Compatible Slots | 1 x PCI Express x1 |
| Interfaces | 1 x 1000Base-T - RJ-45 |
| Miscellaneous | |
| Compliant Standards | FCC, RoHS |
| Included Accessories | Low-profile bracket |
| Software / System Requirements | |
| OS Required | Microsoft Windows Server 2003, Microsoft Windows Server 2008 R2, Microsoft Windows Server 2012, Microsoft Windows Server 2012 R2, Apple MacOS X 10.6 - 10.9, Microsoft Windows Server 2016, Microsoft Windows 2000/XP/Vista/7/8/8.1/10, Linux 2.4.x to 4.1 |
| Dimensions & Weight | |
| Depth | 12 cm |
| Height | 8 cm |
| Weight | 36 g |
| Width | 2 cm |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - 2 years |
| Environmental Parameters | |
| Humidity Range Operating | 10 - 90% |
| Max Operating Temperature | 70 °C |
| Min Operating Temperature | 0 °C |
| Compatibility Information | |
| Designed For | P/N: ET91000SM10, ET91000SM20 |
.jpg)
.jpg)
.jpg)
.jpg)
.jpg)
Add a 10/100/1000Mbps Ethernet port to any PC through a PCI Express slot
The PCIe Gigabit Ethernet Network Card adds a 10/100/1000 Mbps compatible RJ45 Ethernet port to a PCI Express-enabled client, server or workstation, providing a convenient addition or replacement networking interface.
Compliant with IEEE 802.3/u/ab standards, and with support for 9K Jumbo Frames, VLAN tagging and Wake on LAN (WOL), this versatile Gigabit NIC/Server Adapter delivers rock-solid performance.
Plus, the card includes both full profile and low profile/half-height installation brackets for installation in a wide range of computer/server chassis, regardless of form factor.
