Qoltec UPS 2.4kW 3000VA
Qoltec - UPS - AC 80-285 V - 2.4 kW - 3000 VA - 7 At - RS-232, USB - output-stikforbindelser: 4
2 688,00DKK2 150,40DKK excl. VAT
-
Product no 994147355
Model 53043
Brand Qoltec
EAN 5901878530437
Weight kg
-
Product information and specifications are guiding only. Without notice, these can be subject to change by the manufacturer. This applies for product images as well.
| Produktbeskrivelse | Qoltec - UPS - 2.4 kW - 3000 VA |
| Enhedstype | UPS - ekstern |
| Indgangspænding | AC 80-285 V |
| Udgangspænding | AC 230 V ± 1% |
| Strømkapacitet | 2.4 kW / 3000 VA |
| Input-stik | 1 |
| Batteri | - 7 At |
| Antal batterier | 8 |
| Driftstid (op til) | Ved halv belastning |
| Netværk | RS-232, USB |
| Dimensioner (B x D x H) | 19 cm x 42.5 cm x 32.5 cm |
| Producentgaranti | 2 års garanti |
| General | |
|---|---|
| Device Type | UPS - external |
| Power Device | |
| Circuit Protection | Circuit breaker |
| Dataline Surge Protection | Network - RJ-45 - 1 input line / 1 output line |
| Frequency Provided | 50/60 Hz |
| Frequency Required | 45 - 55 Hz ± 0.5Hz |
| Input Connectors | 1 |
| Input Voltage | AC 80-285 V |
| Output Voltage | AC 230 V ± 1% - 50/60 Hz |
| Output Waveform | Sinewave |
| Power Capacity | 2.4 kW / 3000 VA |
| Power Factor (PF) | 0.8 |
| Surge Suppression | Yes |
| UPS Technology | On-line |
| Battery | |
| Capacity | 7 Ah |
| Quantity | 8 |
| Recharge Time | 8 hours |
| Run Time (Up To) | 241 min at 100 Watts | 111 min at 200 Watts | 73 min at 300 Watts | 44 min at 500 Watts | 19 min at 1000 Watts |
| Transfer Time | 0 ms |
| Voltage Provided | 12 V |
| Networking | |
| Remote Management Interface | RS-232, USB |
| Expansion / Connectivity | |
| Expansion Slots | 1 (total) / 1 (free) x Intelligent Slot |
| Interfaces | 1 x management (RS-232) - 9 pin D-Sub (DB-9) | 1 x USB - 4 pin USB Type B |
| Miscellaneous | |
| Cables Included | Power cable - integrated |
| Compliant Standards | RoHS |
| Features | Audible alarm, LCD display, voltage monitoring, internal bypass, overload protection, undervoltage protection, short-circuit protection, Eco-Mode, low voltage protection, double conversion, off-mode charging, Fast Charge technology, load monitoring |
| Software / System Requirements | |
| Software Included | Drivers & Utilities |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - 2 years |
| Environmental Parameters | |
| Humidity Range Operating | 20 - 90% (non-condensing) |
| Max Operating Temperature | 40 °C |
| Min Operating Temperature | 0 °C |
| Sound Emission | 50 dB |
| Dimensions & Weight | |
| Depth | 42.5 cm |
| Height | 32.5 cm |
| Width | 19 cm |
