Product no 991548329
Model FCS-7004
Brand LevelOne
EAN 4015867190319
Weight 0.462 kg
Produktbeskrivelse | LevelOne FCS-7004 - videoserver - 4 kanaler |
Enhedstype | Videoserver - 4 kanaler |
Komprimerings Format | MJPEG, H.264 |
TV System | NTSC/PAL |
Billed Opløsning | 720x480 (NTSC), 720x576 (PAL), 960x576 (PAL), 960x480 (NTSC) |
Dimensioner (B x D x H) | 13.7 cm x 3.55 cm x 12.18 cm |
Vægt | 462 g |
General | |
---|---|
Audio Channels | 4 |
Compliant Standards | EN55024, EN55022 Class B, FCC Part 15 B |
Compression Format | MJPEG, H.264 |
Device Type | Video server |
Image Resolution | 720x480 (NTSC), 720x576 (PAL), 960x576 (PAL), 960x480 (NTSC) |
Package Content | Software, video server |
TV System | NTSC/PAL |
Video Channels | 4 |
Video Server | |
Features | Motion detection, Pan/Tilt/Zoom support, dual stream support, two-way audio support, microSD/SDHC/SDXC memory card slot |
Frame Rate | 30 fps |
Networking | |
Features | Power over Ethernet (PoE) |
Network Interfaces | Ethernet 10Base-T/100Base-TX |
Connections | |
Audio Input Ports | Terminal block x 4 |
Audio Output Ports | Terminal block |
Camera Control Interface (PTZ) | RS-422/485 |
Network Port | 10/100Base-T (PoE) |
Video Input Ports | BNC x 4 |
Video Input Signal Level | 1.0Vp-p 75 Ohm |
Dimensions & Weight | |
Depth | 3.55 cm |
Height | 12.18 cm |
Weight | 462 g |
Width | 13.7 cm |
Environmental Parameters | |
Humidity Range Operating | 10 - 85% (non-condensing) |
Max Operating Temperature | 50 °C |
Min Operating Temperature | -10 °C |
