Product no 993412271
Model SMX750INC
Brand APC
EAN 0731304327745
Weight 25.86 kg
Produktbeskrivelse | APC Smart-UPS X 750VA Tower/Rack - UPS - 600 Watt - 750 VA |
Enhedstype | UPS - stativ-monterbar / ekstern |
Rackstørrelse | 2U |
Vægt | 23 kg |
Indgangspænding | AC 230 V |
Udgangspænding | AC 230 V |
Strømkapacitet | 600 Watt / 750 VA |
Input-stik | Strøm IEC 60320 C14 |
Output-stikforbindelser | 8 x power IEC 60320 C13 |
Batteri | Blysyre |
Driftstid (op til) | 14.2 min ved fuld belastning |
Netværk | RS-232, USB |
Farve | Sort |
Dimensioner (B x D x H) | 43.2 cm x 49.3 cm x 8.9 cm |
Producentgaranti | 3 års garanti |
Designet for | P/N: AR106SH6, AR109SH6, AR112SH6, AR3003, AR3003SP, AR3006, AR3006SP, AR3103, AR3103SP, AR3106, AR3106SP, AR3140G, AR3340G, AR3357X674, AR4018SP, AR4018SPX429, AR4018SPX431, AR4018SPX432, AR4018X429, AR4024IX431, AR4024SP, AR4024SPX429, AR4024SPX431, AR4024SPX432, AR4038IX432, NBWL0356A |
General | |
---|---|
Color | Black |
Device Type | UPS - rack-mountable / external |
Height (Rack Units) | 2U |
Power Device | |
Frequency Provided | 47 - 63 Hz |
Frequency Required | 50/60 Hz ± 3Hz |
Input Connectors | Power IEC 60320 C14 |
Input Voltage | AC 230 V |
Input Voltage Range | AC 160 - 286 V |
Output Voltage | AC 230 V 47 - 63 Hz |
Output Waveform | Sinewave |
Power Capacity | 600 Watt / 750 VA |
Power Output Connectors Details | 8 x power IEC 60320 C13 |
Surge Suppression | Yes |
UPS Technology | Line interactive |
Battery | |
Features | Maintenance free, leak-proof |
Recharge Time | 3 hours |
Run Time (Up To) | 14.2 min at full load | 37 min at half load |
Technology | Lead acid |
Networking | |
Remote Management Interface | RS-232, USB |
Expansion / Connectivity | |
Expansion Slots | 1 (total) / 0 (free) x SmartSlot |
Interfaces | 1 x USB | 1 x RS-232 - RJ-45 | 1 x EPO (emergency power off) |
Miscellaneous | |
Compliant Standards | VDE, EN 62040-2, EAC, RCM, EN 62040-1 |
Software / System Requirements | |
Software Included | APC PowerChute Business Edition |
Manufacturer Warranty | |
Service & Support | Limited warranty - 3 years | Limited warranty - batteries - 2 years |
Dimensions & Weight | |
Depth | 49.3 cm |
Height | 8.9 cm |
Weight | 23 kg |
Width | 43.2 cm |
Compatibility Information | |
Designed For | P/N: ACDC2513, AR106SH6, AR109SH6, AR112SH6, AR2200, AR2280, AR2400, AR2400FP1, AR2401, AR2407, AR2480, AR2487, AR2487G, AR2500, AR2507, AR2580, AR2587, AR3003, AR3003SP, AR3006, AR3006SP, AR3100G, AR3100TAA, AR3100W, AR3103, AR3103SP, AR3105SP, AR31 |
