Product no 998319645
Model TL-SG108-M2
Brand
Go to brand's website
EAN 6935364052904
Weight 1.33 kg
Produktbeskrivelse | TP-Link TL-SG108-M2 - V1 - switch - 8 porte - ikke administreret |
Enhedstype | Switch - 8 porte - ikke administreret |
Undertype | 2.5 Gigabit Ethernet |
Porte | 8 x 100/1000/2.5G |
Præstation | Omkoblingskapacitet: 40 Gbps<br>Pakkevideresendelseshastighed: 29.8 Mpps |
Kapacitet | Pakkebufferstørrelse: 1,5 MB |
MAC adresse table størrelse | 16K indtastningshukommelse |
Jumborammesupport | 10KB |
Egenskaber | Datatransport, auto-negotiation, auto-uplink (auto MDI/MDI-X), gem og send, Quality of Service (QoS), blæserløs, metalkabinet, DiffServ Code Point (DSCP) support |
Overensstemmelsesstandarder | IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3x, IEEE 802.3bz |
Dimensioner (B x D x H) | 22.6 cm x 13.1 cm x 3.5 cm |
General | |
---|---|
Capacity | Packet buffer size: 1.5 MB |
Compliant Standards | IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3x, IEEE 802.3bz |
Device Type | Switch - 8 ports - unmanaged |
Enclosure Type | Desktop, wall-mountable |
Features | Flow control, auto-negotiation, auto-uplink (auto MDI/MDI-X), store and forward, Quality of Service (QoS), fanless, metal housing, DiffServ Code Point (DSCP) support |
Jumbo Frame Support | 10KB |
MAC Address Table Size | 16K entries |
Performance | Switching capacity: 40 Gbps | Packet forwarding rate: 29.8 Mpps |
Ports | 8 x 100/1000/2.5G |
Status Indicators | Power, status |
Subtype | 2.5 Gigabit Ethernet |
Expansion / Connectivity | |
Interfaces | 8 x 100/1000/2.5G RJ-45 |
Power | |
Power Device | External power adapter |
Power Provided | DC 12 V - 1 A |
Miscellaneous | |
Compliant Standards | Plug and Play, FCC, RoHS |
Dimensions & Weight | |
Depth | 13.1 cm |
Height | 3.5 cm |
Width | 22.6 cm |
Environmental Parameters | |
Humidity Range Operating | 10 - 90% (non-condensing) |
Humidity Range Storage | 5 - 95% (non-condensing) |
Max Operating Temperature | 40 °C |
Max Storage Temperature | 70 °C |
Min Operating Temperature | 0 °C |
Min Storage Temperature | -40 °C |
