StarTech.com Netværksadapter PCI Express x4 1Gbps

StarTech.com 4 Port Gigabit PoE (Power over Ethernet) Card - PCIe Network Card - PoE / PoE+ Up to 25W Per Port - PCIe NIC - Gigabit Ethernet Card (ST4000PEXPSE) - Netværksadapter - PCIe x4 - Gigabit Ethernet x 4
2 365,00DKK1 892,00DKK excl. VAT

  • Product no 989508272

    Model ST4000PEXPSE

    Brand StarTech.com

    EAN 0065030855150

    Weight 0.42 kg

  • Product information and specifications are guiding only. Without notice, these can be subject to change by the manufacturer. This applies for product images as well.
Produktbeskrivelse StarTech.com 4 Port Gigabit PoE (Power over Ethernet) Card - PCIe Network Card - PoE / PoE+ Up to 25W Per Port - PCIe NIC - Gigabit Ethernet Card (ST4000PEXPSE) - netværksadapter - PCIe x4 - Gigabit Ethernet x 4
Enhedstype Netværksadapter
Model Indstikskort
Grænseflade (bus) type PCI Express x4
Porte Gigabit Ethernet x 4
Dimensioner (B x D x H) 12 cm x 24 cm x 1.8 cm
Kabeltype Ethernet 10Base-T, Ethernet 100Base-TX, Ethernet 1000Base-T
Dataforbindelsesprotokol 10Mb LAN, 100Mb LAN, 1GbE
Dataoverførselshastighed 1 Gbps
Processor Realtek Semiconductor RTL8111E
Overensstemmelsesstandarder IEEE 802.3, IEEE 802.3u, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3af, IEEE 802.3x, IEEE 802.3at, IEEE 802.3az
Systemkrav Microsoft Windows Server 2003, Microsoft Windows Server 2008 R2, Microsoft Windows Server 2012, Microsoft Windows Server 2012 R2, Microsoft Windows Server 2016, Microsoft Windows 2000/XP/Vista/7/8/8.1/10, Linux 2.4.x to 4.11.x LTS versions only, Microsoft Windows Server 2019
Producentgaranti 2 års garanti
General
Device Type Network adapter
Form Factor Plug-in card
Interface (Bus) Type PCI Express x4
Networking
Cabling Type Ethernet 10Base-T, Ethernet 100Base-TX, Ethernet 1000Base-T
Compliant Standards IEEE 802.3, IEEE 802.3u, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3af, IEEE 802.3x, IEEE 802.3at, IEEE 802.3az
Connectivity Technology Wired
Data Link Protocol Ethernet, Fast Ethernet, Gigabit Ethernet
Data Transfer Rate 1 Gbps
Features Full duplex capability, power over Ethernet (PoE), auto-uplink (auto MDI/MDI-X), Jumbo Frames support, 48KB packet buffer
Ports Gigabit Ethernet x 4
Status Indicators PoE, link/activity
Processor / Memory
Processor Realtek Semiconductor RTL8111E
Expansion / Connectivity
Interfaces 4 x 1000Base-T (PoE) - RJ-45 (external) | 1 - 4 pin internal power (internal) | 1 - 15 pin Serial ATA power (internal)
Miscellaneous
Compliant Standards FCC, RoHS
Software / System Requirements
OS Required Microsoft Windows Server 2003, Microsoft Windows Server 2008 R2, Microsoft Windows Server 2012, Microsoft Windows Server 2012 R2, Microsoft Windows Server 2016, Microsoft Windows 2000/XP/Vista/7/8/8.1/10, Linux 2.4.x to 4.11.x LTS versions only, Micr
Software Included Drivers & Utilities
Dimensions & Weight
Depth 24 cm
Height 1.8 cm
Width 12 cm
Manufacturer Warranty
Service & Support Limited warranty - 2 years
Environmental Parameters
Humidity Range Operating 10 - 90% (non-condensing)
Max Operating Temperature 55 °C
Min Operating Temperature 0 °C

Add 4 Gigabit Power over Ethernet ports to a PCI Express-enabled computer

  • Four 10/100/1000 Mbps compatible PoE RJ45 ports
  • Fully compliant with IEEE 802.3at (Type 1 & 2) Power over Ethernet standards
  • Power Sourcing Equipment (PSE) supports up to 48V, 25.5 Watts max. output per port
Add 4 Gigabit Power over Ethernet ports to a PCI Express-enabled computer
slide {0} of {1}, zoom in, Add 4 Gigabit Power over Ethernet ports to a PCI Express-enabled computer
slide {0} of {1}, zoom in, Add 4 Gigabit Power over Ethernet ports to a PCI Express-enabled computer
slide {0} of {1}, zoom in, Add 4 Gigabit Power over Ethernet ports to a PCI Express-enabled computer
slide {0} of {1}, zoom in, Add 4 Gigabit Power over Ethernet ports to a PCI Express-enabled computer
slide {0} of {1}, zoom in, Add 4 Gigabit Power over Ethernet ports to a PCI Express-enabled computer
slide {0} of {1}, zoom in, Add 4 Gigabit Power over Ethernet ports to a PCI Express-enabled computer
Position your network devices where power outlets aren’t available, with 25.5 Watts per-port PoE output

Position your network devices where power outlets aren’t available, with 25.5 Watts per-port PoE output

Each port can provide up to 25.5W of power, combining network data and power over a single Ethernet cable for reduced cable clutter and added convenience for remote PoE devices.
Reduce expenses by using existing standard Cat5 (or better) Ethernet cabling to deliver power and data

Reduce expenses by using existing standard Cat5 (or better) Ethernet cabling to deliver power and data

The PCI express PoE card supports the IEEE 802.3at (Type 1 and 2) standard for Power Sourcing Equipment (PSE), and can deliver up to 48V DC power to compliant Powered Devices (PD). This eliminates the need for a separate power source and data connection for PoE devices such as IP cameras, IP phones or wireless access points.
Optimize network traffic with support for advanced features, like Jumbo Frames and VLAN tagging

Optimize network traffic with support for advanced features, like Jumbo Frames and VLAN tagging

Suitable for any standard profile PCIe-enabled client, server or workstation, the PoE network card supports features such as Jumbo Frames (up to 9KB), VLAN tagging and Wake on LAN (WoL).

Applications

  • Create a host computer for networked security cameras situated in remote areas, where standard power connection is not possible
  • Install PoE-powered Wireless Access Points (WAP) or repeaters in industrial, warehousing or business environments
  • Enable remote installation of touchscreens or information kiosks
