HPE FlexNetwork 5520 48G 4SFP+ HI 1-slot Switch Switch 48-porte 10 Gigabit Ethernet
HPE FlexNetwork 5520 48G 4SFP+ HI 1-slot Switch - Switch - L3 - Administreret - 48 x 10/100/1000 + 4 x 1 Gigabit / 10 Gigabit SFP+ - side til ryg-luftstrøm - monterbar på stativ - CTO
75 087,00 DKK
60 069,60 DKK excl. VAT
-
Product no 1002110681
Model R8M26A
Brand Aruba Networks
EAN 0190017526089
Weight 7 kg
-
Product information and specifications are guiding only. Without notice, these can be subject to change by the manufacturer. This applies for product images as well.
| Produktbeskrivelse | HPE FlexNetwork 5520 48G 4SFP+ HI 1-slot Switch - switch - 48 porte - Administreret - monterbar på stativ |
| Enhedstype | Switch - 48 porte - L3 - Administreret - kan stables |
| Pakningstype | Side til ryg-luftstrøm monterbar på stativ 1U |
| Undertype | 10 Gigabit Ethernet |
| Porte | 48 x 10/100/1000 + 4 x 1 Gigabit / 10 Gigabit SFP+ |
| Præstation | Latens (1000 Mbps): 5 µs<br>Latens (10 Gbps): 3 µs<br>Kapacitet: 180 Mbps<br>Routing/switching kapacitet: 288 Gbps |
| Kapacitet | IPv4 indtastning i routing-tabel: 32768<br>IPv6 indtastning i routing-tabel: 16384 |
| MAC adresse table størrelse | 64K indtastningshukommelse |
| Jumborammesupport | 10.000 byte |
| Routingprotokol | OSPF, RIP, IS-IS, BGP, IGMPv2, IGMP, VRRP, PIM-SM, statisk IP routing, PIM-DM, IGMPv3, OSPF for IPv6, OSPFv3, PIM-SSM, statisk IPv4 routing, statisk IPv6 routing, ECMP, RIPng, IS-ISv6, BGP-4+, MPLS, Bidirectional Forwarding Detection (BFD), CIDR |
| Protokol til fjernadministration | SNMP 1, RMON 1, RMON 2, SNMP, RMON 3, RMON 9, RMON, Telnet, SNMP 3, SNMP 2c, HTTP, TFTP, SSH, SSH-2, CLI, SCP, SNMP 6, NTP, ICMP, DHCP, RADIUS |
| Egenskaber | Datatransport, Layer 3 switching, DHCP-understøttelse, understøttet af BOOTP, understøttet af ARP, understøttet af MPLS, VLAN-understøttet, auto-uplink (auto MDI/MDI-X), IGMP snooping, Syslog understøttet, DiffServ understøttet, WRR kø, IPv6 understøttet, fuld dupleksmodus, WFQ, WRED, sFlow, STP support, RSTP support, VRRP support, MSTP support, DHCP snooping, ACL support, QoS, RADIUS support, DHCP server, MDL snooping, DLDP support, RRPP, ECMP, BFD, STP Root Guard, IPv4 support, DWRR, LLDP support, DHCP videresendelse, LACP, Port Security, Energy Efficient Ethernet, dynamisk ARP beskyttelse, DHCP beskyttelse, MVRP, portisolering, SP, GARP, 4 MB pakkebuffer, 802.1x autentificering, ToS, MACsec support, OpenFlow support, VPLS, IP-kildebekyttelse, ICMP IRDP, Link Aggregation, VLAN Double Tagging (Q-in-Q), LLDP-MED, Smart Link, Guest VLAN, proxy ARP, WRR, hot swap-blæserbakke, LPM support, IRF Technology, BPDU-beskyttelse, UDP support, MRP |
| Overensstemmelsesstandarder | IEEE 802.3, IEEE 802.3u, IEEE 802.3i, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3af, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.3ae, IEEE 802.3ac, IEEE 802.1s, IEEE 802.1ad, IEEE 802.3ah, IEEE 802.1v, ANSI/TIA-1057, IEEE 802.1ab (LLDP), IEEE 802.1ak, IEEE 802.3at, IEEE 802.3az, IEEE 802.1AX, IEEE 802.1r |
| Effekt | AC 100-240 V (50/60 Hz) - strømforsyning ikke installeret |
| Dimensioner (B x D x H) | 44 cm x 36 cm x 4.36 cm |
| Vægt | 7 kg |
| Pristype | CTO |
| Producentgaranti | Begrænset livtidsgaranti |
HPE Networking Comware Switch 48G 10/100/1000BASE-T 4 10G/1G BASE-X 5520HI
The HPE Networking Comware Switch Series 5520 HI delivers superior performance, high availability and manageability with advanced features at the access and aggregation layer of medium and large enterprise networks. These switches deliver faster performance and advanced L3 features with support for larger ARP/MAC tables and Longest Prefix Match (LPM). VXLAN and EVPN enable greater scalability. Support for Virtual Router Redundancy Protocol (VRRP), Equal-Cost Multipath (ECMP) and Bi-directional Forwarding Detection (BFD) provide resiliency. Intelligent Resilient framework (IRF) ensures high availability. Support for IPv4/IPv6, OpenFlow, and MPLS/VPLS features for investment protection with an easy transition from IPv4 to IPv6 networks. These switches also include SmartMC at no additional cost, and when combined with Intelligent Management Center (IMC), it provides both embedded network management and enhanced network visibility.
Larger MAC tables (up to 64K), Longest Prefix Match (LPM), switching capacity of up to 336 Gbps and throughput of upto 180 Mpps enable faster switching.
Smart Management Center (SmartMC) provides centralized network management and maintains dispersed network edge devices at no additional cost.
Virtual Extensible LAN (VXLAN) and Ethernet VPN (EVPN) enable both isolation and greater scalability of L2/L3 overlay services and multicast.
New made in USA TAA-compliant SKUs offer heightened security via manual and automated source code analysis to address common programming issues, easing concerns about 'made in China' products.
Powerful Performance
- The HPE Networking Comware Switch Series 5520 HI provides medium and large enterprise networks with increased processing power, Larger MAC size tables, and Longest Prefix Match (LPM) to improve network performance and scalability by enabling multipathing.
- Non-blocking architecture delivers up to 336 Gbps of wire-speed switching and up to 180 Mpps throughput.
- Supports Equal-Cost Multipath that enables multiple equal-cost links in a routing environment to increase link redundancy and scale bandwidth.
Highly Resilient and Scalable Access Layer Switches
- The HPE Networking Comware Switch Series 5520 HI uses Intelligent Resilient Framework (IRF) that supports virtualization of up to nine physical switches into one logical device for simpler, flatter, and more agile networks.
- Delivers outstanding resiliency, security, and multiservice support capabilities for traditional large enterprise networks. It supports advanced technologies such as OAM, RRPP, BFD, Multi-level QoS, MPLS, and VPLS.
- Dual, redundant, hot-swappable power supplies maintain a dynamic network that delivers up to 1440 Watts of PoE+ for powered cameras, phones, and wireless access points.
- Supports Virtual Routing Redundancy Protocol (VRRP) where groups of two routers can dynamically back each other up to create highly available routed environments.
- Virtual Extensible LAN (VXLAN) and Ethernet VPN (EVPN) allow greater flexibility to integrate into existing networks, better scalability without redesigning the underlay network, enhanced security to restrict attacks, and improved performance specially in spine-leaf architectures.
Robust Quality of Service (QoS)
- The 5520 HI Series supports advanced classifier-based QoS which groups traffic using multiple match criteria based on Layer 2 and 3 information; it applies QoS policies such as setting priority level and rate limit to selected traffic on a port, VLAN, or the entire switch.
- Provides extensive traffic prioritization with strict priority (SP) queuing, weighted round robin (WRR), weighted fair queuing (WFQ), weighted random early discard (WRED), weighted deficit round robin (WDRR), SP+WDRR, and SP+WFQ.
- Broadcast control and limitation of broadcast traffic rate can reduce unwanted network traffic
Comprehensive Security and Simplified Management
- The 5520 HI Series supports flexible authentication methods including 802.1X and MAC Authentication and Encryption for greater device security and policy-driven application authentication. Per-user Access Control Lists (ACLs) provide identity-driven security and access control.
- Dynamic ARP protection with functions such as ARP Detection and ARP packet validation that block broadcasts from unauthorized hosts, prevent eavesdropping or theft of network data.
- Centralized security policy management and network protection with HPE Intelligent Management Center (IMC), which leverages End User Admission Domination (EAD) integrated security policies, network access control and access right control policies for a comprehensive integrated security system.
- Supports SmartMC, an embedded network management tool, with a web-based GUI to simplify operations and facilitate centralized management at no additional cost. It offers features such as configuration backup, software version management, and seamless switch replacement.
Specifications
| TechnicalSpecifications | |
|---|---|
| Ports | (48) RJ-45 autosensing 10/100/1000 BASE-T ports Duplex: Ports 1-48 support 10BASE-T/100BASE-TX, 1000BASE-T (full only), (4) SFP+ 1/10GbE ports, (1) port expansion module slot. |
| Memory and processor | 2 GB SDRAM Packet buffer size: 4 MB, 512 MB flash |
| Latency | 1000 Mb Latency: < 5 µs 10 Gbps Latency: < 3 µs |
| Throughput | up to 180 Mpps |
| Routing/switching capacity | 336 Gbps |
| Switching capacity | 336 Gbps |
| Stacking capabilities | IRF 9 switches |
| Management features | IMC - Intelligent Management Center Command-line interface SNMP manager |
| Input voltage | 90 to - 264 VAC and -36 to -72 VDC |
| Power consumption | 150W (maximum) |
| Heat dissipation | Ranges from 81 BTU/hr to 327BTU/hr depending on power supply configuration |
| Product dimensions (metric) | 44 X 36 X 4.36 cm |
| Weight | ≤7.0kg |
