HighPoint SSD7505 Styreenhed til lagring (RAID)
HighPoint SSD7505 - Styreenhed til lagring (RAID) - M.2 - 4 Kanal - M.2 NVMe Card - RAID 0, 1, 10 - PCIe 4.0 x16
6 620,00 DKK
5 296,00 DKK excl. VAT
-
Product no 996589613
Model SSD7505
Brand HighPoint Technologi
EAN 0643653750511
Weight 0.6 kg
-
Product information and specifications are guiding only. Without notice, these can be subject to change by the manufacturer. This applies for product images as well.
| Produktbeskrivelse | HighPoint SSD7505 - styreenhed til lagring (RAID) - M.2 NVMe Card - PCIe 4.0 x16 |
| Enhedstype | Styreenhed til lagring (RAID) - indstikskort |
| Bustype | PCIe 4.0 x16 |
| Harddiskens formfaktorkompatibilitet | M.2 |
| Interface | M.2 NVMe Card |
| Dataoverførselshastighed | 16 GBps |
| Understøttede enheder | Diskarray (RAID), solid state drev |
| Antal kanaler | 4 |
| Maks. antal lagerenheder | 4 |
| RAID-niveau | RAID 0, RAID 1, RAID 10 |
| Systemkrav | Microsoft Windows Server 2012 R2, Windows 10, Linux Kernel 3.10 eller nyere, Apple MacOS 10.13 eller nyere |
| Dimensioner (B x D x H) | 1.91 cm x 19.5 cm x 11.2 cm |
| Vægt | 581 g |
| General | |
|---|---|
| Device Type | Storage controller (RAID) - plug-in card |
| Hard Drive Form Factor Compatibility | M.2 |
| Host Bus | PCIe 4.0 x16 |
| Storage Controller | |
| Channel Qty | 4 |
| Data Transfer Rate | 16 GBps |
| Interface | M.2 NVMe Card |
| Max Storage Devices Qty | 4 |
| RAID Level | RAID 0, RAID 1, RAID 10 |
| Supported Devices | Disk array (RAID), solid state drive |
| Expansion / Connectivity | |
| Connections | 1 x PCIe 4.0 x16 |
| Interfaces | 4 x M.2 Card (internal) |
| Miscellaneous | |
| Compliant Standards | FCC, RoHS, WEEE, REACH |
| Features | Automatic disk rebuild, Bootable RAID Array support, S.M.A.R.T. support, supports NVM Express, full-height, passively cooled, SMTP support, Storage Health Inspector |
| MTBF | 920,585 hours |
| Software / System Requirements | |
| OS Required | Microsoft Windows Server 2012 R2, Windows 10, Linux Kernel 3.10 or later, Apple macOS 10.13 or later |
| Dimensions & Weight | |
| Depth | 19.5 cm |
| Height | 11.2 cm |
| Weight | 581 g |
| Width | 1.91 cm |
| Environmental Parameters | |
| Max Operating Temperature | 55 °C |
| Min Operating Temperature | 5 °C |
