D-Link DGS 1510-28P Switch 28-porte Gigabit PoE+
D-Link DGS 1510-28P - Switch - L3 - smart - 24 x 10/100/1000 (PoE+) + 2 x Gigabit SFP + 2 x 10 Gigabit SFP+ - desktop, monterbar på stativ - PoE+ (193 W)
5 573,00DKK4 458,40DKK excl. VAT
-
Product no 1000623870
Model DGS-1510-28P/E
Brand D-Link
EAN 0790069467936
Weight 3.67 kg
-
Product information and specifications are guiding only. Without notice, these can be subject to change by the manufacturer. This applies for product images as well.
| Produktbeskrivelse | D-Link DGS 1510-28P - switch - 28 porte - smart - monterbar på stativ |
| Enhedstype | Switch - 28 porte - L3 - smart - kan stables |
| Pakningstype | Monterbar på stativ |
| Undertype | Gigabit Ethernet |
| Porte | 24 x 10/100/1000 (PoE+) + 2 x Gigabit SFP + 2 x 10 Gigabit SFP+ |
| Power Over Ethernet (PoE) | PoE+ |
| PoE-budget | 193 W |
| Præstation | Omkoblingskapacitet: 92 Gbps<br>Videresendelsespræstation (64-byte pakkestørrelse): 68,45 Mpps<br>Stablende båndbredde: 40 Gbps |
| Kapacitet | Statiske MAC-poster: 512<br>ARP-indtastninger: 256<br>IPv6 router: 32<br>IPv4 router: 64 |
| MAC adresse table størrelse | 16.384 indtastninger |
| Jumborammesupport | 9216 byte |
| Routingprotokol | IGMPv2, IGMP, statisk IP routing, IGMPv3, MLDv2, MLD |
| Protokol til fjernadministration | SNMP 1, RMON 1, Telnet, SNMP 3, SNMP 2c, HTTP, TFTP, CLI |
| Egenskaber | Datatransport, komplet duplex ydeevne, auto-negotiation, auto-uplink (auto MDI/MDI-X), DoS attack beskyttelse, portspejling, IPv6 understøttet, STP support, RSTP support, MSTP support, ACL support, QoS, Cable Diagnostics Function, IPv4 support, LLDP support, SPQ, Multicast filtreringsfunktion, 2 blæsere, 1,5 MB pakkebuffer, Protokol-baseret VLANs support, DRR, LLDP-MED, WRR, MAC based VLAN, HOL Blocking Prevention, tilbageløkke-detektion, ARP spoofing, Asymmetric VLAN, anti-stemme-VLAN |
| Overensstemmelsesstandarder | IEEE 802.3, IEEE 802.3u, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.3ae, IEEE 802.1s, IEEE 802.3az |
| Effekt | AC 120/230 V (50/60 Hz) |
| Dimensioner (B x D x H) | 44 cm x 21 cm x 4.4 cm |
| Vægt | 2.54 kg |
| Producentgaranti | Begrænset livtidsgaranti |
| General | |
|---|---|
| Authentication Method | RADIUS, TACACS+, Secure Shell v.2 (SSH2) |
| Capacity | Static MAC entries: 512 | ARP entries: 256 | IPv6 routes: 32 | IPv4 routes: 64 |
| Compliant Standards | IEEE 802.3, IEEE 802.3u, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.3ae, IEEE 802.1s, IEEE 802.3az |
| Device Type | Switch - 28 ports - L3 - smart - stackable |
| Enclosure Type | Desktop, rack-mountable |
| Encryption Algorithm | SSL, TLS, SSL 3.0, SSL 2.0, PEAP, TTLS |
| Features | Flow control, full duplex capability, auto-negotiation, auto-uplink (auto MDI/MDI-X), DoS attack prevention, port mirroring, IPv6 support, Spanning Tree Protocol (STP) support, Rapid Spanning Tree Protocol (RSTP) support, Multiple Spanning Tree Proto |
| Jumbo Frame Support | 9216 bytes |
| MAC Address Table Size | 16384 entries |
| Max Units In A Stack | 6 |
| Performance | Switching capacity: 92 Gbps | Forwarding performance (64-byte packet size): 68.45 Mpps | Stacking bandwidth: 40 Gbps |
| PoE Budget | 193 W |
| Ports | 24 x 10/100/1000 (PoE+) + 2 x Gigabit SFP + 2 x 10 Gigabit SFP+ |
| Power Over Ethernet (PoE) | PoE+ |
| Remote Management Protocol | SNMP 1, RMON 1, Telnet, SNMP 3, SNMP 2c, HTTP, TFTP, CLI |
| Routing Protocol | IGMPv2, IGMP, static IP routing, IGMPv3, MLDv2, MLD |
| Status Indicators | Power, error, PoE, fan, link/activity/speed, stack |
| Subtype | Gigabit Ethernet |
| Expansion / Connectivity | |
| Interfaces | 24 x 1000Base-T RJ-45 PoE+ - 30 W | 2 x 1000Base-X SFP | 2 x 10GBase-X SFP+ |
| Power | |
| Power Consumption Stand by | 21 Watt |
| Power Device | Internal power supply |
| Voltage Required | AC 120/230 V (50/60 Hz) |
| Miscellaneous | |
| Compliant Standards | VCCI, C-Tick, BSMI, cUL, CB, CCC, FCC, IPv6 Ready |
| MTBF | 275,428 hours |
| Dimensions & Weight | |
| Depth | 21 cm |
| Height | 4.4 cm |
| Weight | 2.54 kg |
| Width | 44 cm |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - lifetime |
| Environmental Parameters | |
| Humidity Range Operating | 0 - 95% (non-condensing) |
| Humidity Range Storage | 0 - 95% (non-condensing) |
| Max Operating Temperature | 50 °C |
| Max Storage Temperature | 70 °C |
| Min Operating Temperature | -5 °C |
| Min Storage Temperature | -20 °C |
